Compressors Type Evaporative Heat and Cool Heat Pump

Name: Compressors Type Evaporative Heat and Cool Heat Pump
Brand: JNOD
Rating: 5.0 (89 reviews)

Energy Efficiency Grade: One
Heat Temperature: 55 Degree Centigrade
Work Environment: Low-temperature Heat Pump
Heat Source: Air-source
Heating Type: Multi-power Heat
Application: Villa Family, Hotels, Factory Hospital, Student Apartments, Beauty Salons

Model:
JM220HC
Brand:
JNOD

Availability:

Quantity:



Inquire Add to Basket

JNOD R32 EVI Compressors Type Evaporative Heat and Cool Heat Pump.

*Air to Water heat pump water heaters for heating and hot water

*WiFi Remote Control

The heating and cooling heat pump can be controlled by Wi-Fi, it release the users that can operate their heat pumps anytime and anywhere.

*Three in One Function Mode

Domestic Hot Water(DHW)+ Heating + Cooling.

*Panasonic Compressor

EVI system can ensure stable and safe operation of unit under -25℃ ambient temperature.

*Supper high efficiency A+++ Erp for heating and cooling heat pump.

*-25℃ ultra low temperature

It can be installed in an environment of -25 degree celcius, and its technology with EVI is specially for ultra-low temperature.

*RS485 serial port

It is highlighted with central control system.

swimmingpoolwaterheater_09 swimmingpoolwaterheater_10 swimmingpoolwaterheater_11

Model		JM95HC	JM120HC	JM150HC	JM200HC	JM220HC
Heating Capacity Range(kw)		2-9.5	2.8-12	3.5-15	4.5-20	5-22
Heating (A7/6℃,W30/35℃)	Heating Capacity	9.5	11.5	15.2	19.5	22
	Power Input	2.18	2.60	3.53	4.51	5.13
	Cop	4.35	4.4	4.31	4.32	4.29
Heating (A-12℃,W36/41℃)	Heating Capacity	6.83	7.8	10.2	12.8	14.6
	Power Input	2.79	3.12	3.91	4.96	5.77
	Cop	2.45	2.52	2.61	2.58	2.53
Heating (A7/6℃,W40/45℃)	Heating Capacity	9.4	11.4	14.8	19.2	21.8
	Power Input	2.72	3.37	4.30	5.45	6.23
	Cop	3.45	3.38	3.44	3.52	3.5
Heating (A7/6℃,W47/55℃)	Heating Capacity	9.2	11.3	14.17	18.1	21.3
	Power Input	3.14	3.79	4.87	5.99	7.15
	Cop	2.93	2.98	2.91	3.02	2.98
Cooling (A35/24℃,W23/18℃)	Cooling Capacity	8.6	10.4	13.3	16.82	17.8
	Power Input	2.51	2.96	3.73	4.65	4.97
	Cop	3.43	3.51	3.57	3.62	3.58
Cooling (A35/24℃,W12/7℃)	Cooling Capacity	7.8	8.9	11.2	13.1	13.5
	Power Input	2.84	3.28	4.10	4.75	4.95
	Cop	2.75	2.71	2.73	2.76	2.73
Max Power Input		3.1	3.8	5.2	6.14	6.9
Max Current		14	18.2	24.9	29.4	33.01
Wifi Control		YES
Controller		LED
Power Supply		220-240V/50Hz/60Hz
Operating Air Temp.		-25~43
Max Outlet Water Temp.		55
Refrigerant		R32
Fan Quantity		1			2
Compressor Brand		Panasonic (Rotary)
Brand of EEV		SANHUA
Brand of 4-way valve		SANHUA
Heat Exchanger		Plate heat exchanger
Casing Material		Galvanized Sheet
Water Pipe connection		G1"(female thread)
Noise Level at 1m dB(A)		46	48	52	55	56
Water Flow (m³/h)		1.5	2.06	2.6	3.44	3.78
Water Pressure Drop		14	14	16	20	20
Min/Max heating water pressure (bar)		2.0/10.0
Net Dimensions(L/W/H)		1127475810		1127475960	11274751360
Package Dimensions(L/W/H)		1195535960		11955351110	11955351510
Net Weight KG		91	92	103	120	120
Gross Weight KG		106	107	120	145	145
Loading quantity 20GP/40GP,40HQ pcs		44/96/96/		22/48/48

Model		JM95HC3N	JM120HC3N	JM150HC3N	JM200HC3N	JM220HC3N	JM260HC3N	JM320HC3N
Heating Capacity Range(kw)		2-9.5	2.8-12	3.5-15	4.5-20	5-22	13.1-26	16.6-32
Heating (A7/6℃,W30/35℃)	Heating Capacity	9.5	11.5	15.2	19.5	22	26	32
	Power Input	2.18	2.60	3.53	4.51	5.13	6.16	7.69
	Cop	4.35	4.4	4.31	4.32	4.29	4.22	4.16
Heating (A-12℃,W36/41℃)	Heating Capacity	6.83	7.8	10.2	12.8	14.6	17.2	19.4
	Power Input	2.79	3.12	3.91	4.96	5.77	6.88	7.95
	Cop	2.45	2.52	2.61	2.58	2.53	2.5	2.44
Heating (A7/6℃,W40/45℃)	Heating Capacity	9.4	11.4	14.8	19.2	21.8	24.7	30.5
	Power Input	2.72	3.37	4.30	5.45	6.23	7.04	8.79
	Cop	3.45	3.38	3.44	3.52	3.5	3.51	3.47
Heating (A7/6℃,W47/55℃)	Heating Capacity	9.2	11.3	14.17	18.1	21.3	24.2	29.3
	Power Input	3.14	3.79	4.87	5.99	7.15	8.29	10.10
	Cop	2.93	2.98	2.91	3.02	2.98	2.92	2.9
Cooling (A35/24℃,W23/18℃)	Cooling Capacity	8.6	10.4	13.3	16.82	17.8	19.5	24.1
	Power Input	2.51	2.96	3.73	4.65	4.97	5.70	7.13
	Cop	3.43	3.51	3.57	3.62	3.58	3.42	3.38
Cooling (A35/24℃,W12/7℃)	Cooling Capacity	7.8	8.9	11.2	13.1	13.5	15.6	18.6
	Power Input	2.84	3.28	4.10	4.75	4.95	5.82	7.02
	Cop	2.75	2.71	2.73	2.76	2.73	2.68	2.65
Max Power Input		3.1	3.8	5.2	6.14	6.9	8.85	11.4
Max Current		5.6	6.8	9.3	10.9	12.3	15.8	20.4
Wifi Control		YES
Controller		LED
Power Supply		220-240V/50Hz/60Hz
Operating Air Temp.		-25~43
Max Outlet Water Temp.		55
Refrigerant		R32
Fan Quantity		1			2
Compressor Brand		Panasonic (Rotary)
Brand of EEV		SANHUA
Brand of 4-way valve		SANHUA
Heat Exchanger		Plate heat exchanger
Casing Material		Galvanized Sheet
Water Pipe connection		G1"(female thread)					G1.5"(female thread)
Noise Level at 1m dB(A)		46	48	52	55	56	57	58
Water Flow (m³/h)		1.5	2.06	2.6	3.44	3.78	4.47	5.5
Water Pressure Drop		14	14	16	20	20	21	22
Min/Max heating water pressure (bar)		2.0/10.0
Net Dimensions(L/W/H)		1127475810		1127475960	11274751360		11274751560
Package Dimensions(L/W/H)		1195535960		11955351110	11955351510		11955351710
Net Weight KG		91	92	103	120	120	150	160
Gross Weight KG		106	107	120	145	145	180	1
Loading quantity 20GP/40GP,40HQ pcs		44/96/96/		22/48/48
